AMD Ryzen 7 9800X3D CPU, 8 Cores & 16 Threads, 5.2GHz Boost, DDR5, PCIe 5.0

 Short Summary

The AMD Ryzen™ 7 9800X3D is an 8-core, 16-thread unlocked desktop processor built on Zen 5 architecture. Featuring a base clock of 4.7GHz and boost up to 5.2GHz, it supports DDR5-5600 memory, PCIe® 5.0, and integrated Radeon™ Graphics. With 96MB L3 cache and advanced AMD technologies like EXPO™, Precision Boost Overdrive, and Curve Optimizer, it delivers unmatched gaming and multitasking performance.

 Detailed Description

• Zen 5 Architecture: Advanced 4nm design for high efficiency and superior performance.

• Core Power: 8 cores and 16 threads for heavy multitasking and gaming workloads.

• High Clock Speeds: Base clock 4.7GHz, boost up to 5.2GHz with Precision Boost 2.

• Unlocked for Overclocking: Supports Precision Boost Overdrive, EXPO™ memory tuning, and Ryzen™ Master.

• Cache Memory: Massive 96MB L3 cache and 8MB L2 cache for faster data access.

• Memory Support: Dual-channel DDR5 up to 5600 MT/s, ECC supported, max 192GB.

• Next-Gen Connectivity: PCIe® 5.0 support with up to 28 lanes for GPU and NVMe expansion.

• Integrated Graphics: AMD Radeon™ Graphics with 2 cores at 2200 MHz.

• Storage Options: NVMe boot support and RAID 0, 1, 5, 10 for high-speed storage arrays.

• Compatibility: Works with AM5 socket motherboards (X870, B650, X670, A620, etc.).

• Cooling Recommendation: Liquid cooling recommended for optimal performance.

• OS Support: Windows 11/10 64-bit, Ubuntu, and RHEL Linux.

• Power Efficiency: Default TDP 120W with maximum safe operating temperature 95°C.
